Microscope
MODEL 2000E
Specifications:
*Eye Piece Magnifications: 12.5/18B
*Adjustable Diopter: 6D
*Adjustable Range for Pupil Distance: 55mm75mm
*Magnifications for Main Microscope: 4.627zoom magnification
*Diameter of Field:F46 F8.5mm
*Magnifications for Assistant Microscope: 6.29.314
*Objective Focus: f=200mm
*Optional Objectives: f=250mm/300mm/350mm/400mm
*Working Distance: 195mm
*Maximal Resolution: 126LP/mm
*Illumination Source: 15V/150W,medical cold-reflection halogen lamp
*Illumination Type: 6coaxial illumination,62coaxial illumination
*Maximal Illumination:50000lx
*Filter: UV&IR filter, yellow spot protection filter, redfree,GG435,GG475
*Maximal Height for Microscope: 1710mm
*Reaching Radius of Arm: 1320mm
*Adjustable Vertical Range: 710mm~1310mm
*Fine Focusing Speed and Range: 2mm/s,50mm
*Speed for X/Y and Range: 2mm/s ,50mm50mm
*Arthrosis Fixation: Electromagnetic Lock
MODEL 102
Specification:
*Observation angle: 45tilted
*Magnification of binocular: 6X
*Interpupillary distance: 50mm-80mm
*Diopter: 5D
*Focal length of objective: F=200mm and F=300mm two objectives
*Magnification changer: 3-step: 0.6X, 1X, 1.6X
*Total magnification: 3X, 5X, 8X, 4.7X, 7.5X, 12X
*Linear field: 60.8mm, 37.9mm, 23.6mm, 40.6mm, 25.3mm, 15.8mm
*Fine focusing distance: 10mm
*Illumination: Coaxial illumination with 10W LED lamp light source, brightness adjustable, illumination>30000lx
*Filter: Build-in green and yellow filters
*Balancing arm: 2-part arm with universal joints
*Floor stand: 2-part column fitted on the five-star base with casters
*Power supply: AC100V-AC240V
*Optional accessories: Objective F=250mm & F=400mm, Wall mount bracket
MODEL 1000LP
*Portable ophthalmic surgical microscope, convenient for assembly and transportation, suitable for field surgery.
*Multi-layer coating with better optical quality.
*mini-motor, function reliable.
*With selected objective lenses for ENT dentalgeneral surgery and laboratory.
Main Specification
Specification:
*Eyepiece: Comfort View 10 Wide Field
*Inclination Angle: 45
*Magnification: 61016
*Working Distance: 160mm
*Focus Speed: 20mmFoot control
*Light Intensity: 60,000 Lux
